HusarWinch BST S 22000 lbs (9979 kg) 24V
1 423.07 €
(w/o VAT:1 120.53 €)
(w/o VAT:1 120.53 €)
HusarWinch BST S 22000 lbs (9979 kg) 24V
Item number:
HWIBSTS22000
Available to order
In external stock: 5 pcs,
Available: 10-12 days
Suitable for every type of car
HusarWinch BST S 22000 lbs (9979 kg) 24V
Application: special passenger cars, commercial vehicles, tugboats
Pull capacity(single line): 22000lbs / 9979 kg
Motor 24V: 6,1 kW / 8,2 LE
Controls: Wired / wireless remote control
Gear: 3-stage planetary
Gear ratio: 370:1
Brake: Automatic
Rope: 30m x Ø 12mm
Fairlead: 4-ways rollers fairlead
Net weight: 73 kg
Mounting bolt pattern: 254 mm × 114,3 mm és 254 mm × 165,1 mm
Dimensions(L x W x H): 635 × 214 × 252 mm
| Line speed and motor current (first layer) | ||||||
| lbs | 0 | 10000 | 14000 | 17000 | 22000 | |
| Line pull | kg | 0 | 4536 | 6350 | 7711 | 9979 |
| Line speed | m/min 24V | 8.4 | 3.3 | 2.1 | 1.4 | 1.1 |
| Motor current | Amper 24V | 35 | 115 | 198 | 220 | 280 |
| Line pull and cable capacity | ||||||
| Layer of cable | 1 | 2 | 3 | 4 | ||
| lbs | 22000 | 17742 | 1465 | 1291 | ||
| Rated line pull per layer | kg | 9979 | 8048 | 6743 | 5802 | |
| Cable capacity per layer | m | 5.6 | 12 | húsz | 28.5 | |
Pull capacity(single line):
22000 lbs/9979 kg
Controls:
vezetékes/ vezeték nélküli távirányító
Gear:
3 fokozatú bolygóműves
Gear ratio:
370:1
Brake:
automata
Rope:
acél
Fairlead :
görgős ablak
Net weight:
73 kg
Mounting bolt pattern:
254 mm × 114,3 mm és 254 mm × 165,1 mm
Dimensions (L x W x H):
635 × 214 × 252 mm
1 423.07 €
(w/o VAT:1 120.53 €)
(w/o VAT:1 120.53 €)
pcs
Husar Winch is a recognized and proven brand that has been operating in the market for many years. Thanks to dynamic development, our products can be found throughout Europe and Asia, where we have become one of the leading brands. Husar Winch offers a wide range of electric, hydraulic, manual, chain, and workshop winches, as well as a wide range of off-road accessories, compressors, worm gears, shackles, ropes, and much more.
The idea and project were first conceived in Profel-Szydłowiec. This factory has been manufacturing winches for the heavy and defense industries in Poland and abroad for many years. Our experience has resulted in the creation of reliable, high-quality products. Thanks to the technology that pays great attention to every detail, we have gained an exceptional reputation in the market.
Husar Winch winches assist in various areas of everyday work:
-
ATV/Quad winches, which hunters prefer to use as game hoists on pickup trucks.
-
Self-recovery winches for 4x4 vehicles, suitable for every load from Suzuki to Mercedes G.
-
Very fast winches for off-road racing cars with our dual-motor solution.
-
On recovery platforms for pulling damaged cars.
-
High-performance 24V and hydraulic winches on off-road trucks.
-
Manual winches on car transporter trailers.
-
In workshops, our high-quality 220V remote-controlled lifting winches are used.
Producer:
HusarWinch
EAN code:
5904024534242
Manufacturer logo:
Warranty :
2 év
Kötél vastagság:
12 mm
Kötél hossz:
30 m
Weight:
73 kg/pcs
