Led bar Purelux Panther C540 - Curved / 54 cm / 216W / Ref. 25
318.69 €
(w/o VAT:250.94 €)
(w/o VAT:250.94 €)
Led bar Purelux Panther C540 - Curved / 54 cm / 216W / Ref. 25
Item number:
HS18106
Available to order
A curved led bar designed for demanding users, which offers great performance and is equipped with e.g. with two different power modes and a really wide combination light pattern! The light also includes an orange and white parking light and a neutral 5000K color temperature. Measured light output 16332 lm, measured range 607 m @ 1 lux.
Color temperature :
5 000 K
Rated power :
216 W
Rated power:
216 W
Rated voltage :
9-36 V (DC)
Connecting :
Deutsch (DT04-2P, DT06-2S)
Light intensity :
17 000 lm
Light intensity:
16332/2573 lm
Standards:
ECE R10, R149
318.69 €
(w/o VAT:250.94 €)
(w/o VAT:250.94 €)
pcs
Specifications
-
- Brand and model: Purelux Panther C540
- Purpose: As an additional light in cars / Off-Road vehicles / work machines
- LED: 36 x 6W
- Operating voltage: 9-36 V (DC)
- Reference number: 25
- Calculated power: 216 W
- Power consumption measured by Valostore
- Purelux PowerBoost®: 8.29A @ 24V
- Road mode: 1.08A @ 24V
- Power measured by Valostore
- Purelux PowerBoost®: 199W @ 24V
- Road mode: 26W @ 24V
- Parking light: 4 W
- Light output declared by the manufacturer: 17000 lm (Purelux PowerBoost®)
- Measured by Valostore: 16332 lm (Purelux PowerBoost®)
- Measured by Valostore: 2573 lm (Traffic condition)
- Range measured by Valostore: 607 m @ 1 lux / 1214 m @ 0.25 lux (Purelux PowerBoost®)
- Range measured by Valostore: 254 m @ 1 lux / 508 m @ 0.25 lux (Traffic mode)
- Color temperature stated by the manufacturer: 5000 K
- Measured by Valostore: 5068 K
- Fastening: End legs, width-adjustable lower legs
- Connector: Deutsch DTP-2
- The parking lights + wires are separate
- Cable length: 50 cm
- Dimensions: 542 x 66 x 70 mm (Width x Height x Depth)
- Height with end legs: 78 mm
- Height with lower legs: 81.5 mm
- Weight: 2340 g
- Radius of curvature: 2800 mm
- IP rating: IP69K
- Approvals: ECE R10, R148, R149*
- *Road traffic approval does not apply to the Purelux PowerBoost® mode
- Other: The panel has ready-made places for stabilizers
- Warranty: 24 months
Producer:
Purelux
Street legal :
igen (ECE engedélyes)
Type of protection:
IP69K
Light distance at 1lx:
470 m
Manufacturer logo:
Weight:
2.5 kg/pcs
