The main advantages of using differential locks include:
• Increased traction: Differential locks enable better utilization of driving power by evenly distributing force to the wheels, allowing for improved traction on difficult terrain.
• Enhanced control: By being able to lock the differential mechanism, the driver gains greater control over the vehicle, which is particularly important in extreme terrain conditions and improves passenger safety.
• Component protection: By improving traction and control, differential locks can also contribute to reducing the wear of other drivetrain components, leading to increased durability and long-term savings.
Regardless of the terrain vehicle model, our differential locks are designed for maximum effectiveness and durability, proving themselves in rally conditions where reliability is crucial. This ensures reliability and durability for our customers even in the toughest terrain conditions. Our company places great emphasis on research and development to provide our customers with products that meet the highest quality and technological standards.
Fits for Toyota:
LandCruiser 71, 76, 78, 79, 100 & 105 Series, Lexus LX470 Live axle suspension 1998 on rear
LandCruiser Prado, 90, 120 and 150 Series, Lexus GX 8" dia. RG, 10 bolt 1996 on rear
LandCruiser 40, 55, 60, 62, 70, 73, 74, 75 & 80 Series,Lexus LX450 10 bolt, full floating 1990 to 97 front
Bundera, LandCruiser II, LJ70, RJ70 10 bolt all years front
Bundera, LandCruiser II, LJ70, RJ70 10 bolt, 45mm bearing ID to 1985 rear (Late model 50.00mm [1.969"] ID carrier bearings (e.g., from FJ/HJ80 model) must be used. This will also improve bearing life.)
Bundera, LandCruiser II, LJ70, RJ70 10 bolt, 45mm bearing ID to 1986 on rear
HiLux, Pickup, Hiace, Fortuner 10 bolt, live axle al years front
HiLux, Pickup, Hiace, Fortuner 4 cylinder, 45mm bearing ID to 1988 rear
HiLux, Pickup, Hiace, Fortuner All models, 50mm bearing ID 1988 to 05 rear
HiLux, Pickup, Hiace, Fortuner Adjuster nut models, 50 or 53mm bearing ID 2005 to 2015 rear
4Runner, LN61, YN63 10 bolt, live axle all years front
4Runner, LN61, YN63 4 cylinder, 45mm bearing ID 1984 to 88 rear
4Runner, LN61, YN63 V6, 4WD & 2WD, 50mm bearing ID 1988 to 2010 rear
FJ Cruiser 8" non-factory locker model 2006 to 09 rear
SPECIFICATIONS
- Axle Spline: 30 tooth, Ø33mm [1.31”]
- Ratio Supported: All
- Ring Gear ID: 126.0mm [4.96”]
- Ring Gear OD: 200mm [8”]
- Ring Gear Bolts: 10 bolts on Ø160mm [6.30”]
- Ring Gear Torque: 95Nm [70 ft-lb]
- Backlash: 0.15-0.25mm [0.006-0.010”]
- Bearing Cap Torque: 95Nm [70 ft-lb]
