HusarWinch hidraulic winch S 12000 lbs (5443 kg)
HusarWinch hidraulic winch S 12000 lbs (5443 kg)
1 593.25 €
(w/o VAT:1 254.53 €)
  1. Hydraulic winches
  1. 4x4 Accessories and Off-road
  2. Winching
  3. Hydraulic winches

HusarWinch hidraulic winch S 12000 lbs (5443 kg)

Item number:
HWIBSTHS12000
HusarWinch hidraulic winch S 12000 lbs (5443 kg)
HusarWinch hidraulic winch S 12000 lbs (5443 kg)
HusarWinch hidraulic winch S 12000 lbs (5443 kg)
1
00
HusarWinch hidraulic winch S 12000 lbs (5443 kg)
HusarWinch hidraulic winch S 12000 lbs (5443 kg)
Available to order
In external stock: 5 pcs,
Available: 10-12 days

HusarWinch hidraulic winch HS 12000 lbs (5443 kg)

BST H 12000 lbs Technical data
Pulling rate (one line) 12000 font (5443 kg)
Motor displacement 100 ml/r
Brake automatic
Oil flow 5-60L/min
Pressure 15 MPa
Gear 2 -stage planetary
Gear ratio 17,6:1
Rope 25,5 m x Ø 10,2 mm 8-M10
Fairlead  4-ways rollers fairlead
Net weight 51 kg
Mounting bolt pattern 374,2 mm × 114,3 mm
Dimensions

(H x Szé x Ma) 519 mm x 235 mm x 246 mm

Line speed and motor current (first layer)
lbs 0 4000 6000 8000 12000
Line pull kg 0 1814 2722 3629 5443
Line speed m/min 0.9 1.8 3.6 7.2 9.5
Pressure PSI 435.1 986,2 1334,3 1740.4 2175
Oil flow l/min 5.0 10.0 20.0 40,0 60,0



Line pull and cable capacity
Layer of cable   1 2 3 4
lbs 12000 8000 6000 4000
Rated line pull per layer kg 5543 3629 2722 1814
Cable capacity per layer m 7 15 18.6 25.5

Pull capacity(single line):
12000 lbs/5443 kg
Gear ratio:
17,6:1
Brake:
automata
Rope:
acél
Fairlead :
görgős ablak
Net weight:
51 kg
Mounting bolt pattern:
374,2 mm × 114,3 mm
Dimensions (L x W x H):
519 x 235 x 246 mm
Oil flow :
5-60L/perc
Oil pressure :
15 Mpa
More details
1 593.25 €
(w/o VAT:1 254.53 €)
pcs
  • Details
  • Data
  • Reviews
Details

Husar Winch is a recognized and proven brand that has been operating in the market for many years. Thanks to dynamic development, our products can be found throughout Europe and Asia, where we have become one of the leading brands. Husar Winch offers a wide range of electric, hydraulic, manual, chain, and workshop winches, as well as a wide range of off-road accessories, compressors, worm gears, shackles, ropes, and much more.

The idea and project were first conceived in Profel-Szydłowiec. This factory has been manufacturing winches for the heavy and defense industries in Poland and abroad for many years. Our experience has resulted in the creation of reliable, high-quality products. Thanks to the technology that pays great attention to every detail, we have gained an exceptional reputation in the market.

Husar Winch winches assist in various areas of everyday work:

  • ATV/Quad winches, which hunters prefer to use as game hoists on pickup trucks.

  • Self-recovery winches for 4x4 vehicles, suitable for every load from Suzuki to Mercedes G.

  • Very fast winches for off-road racing cars with our dual-motor solution.

  • On recovery platforms for pulling damaged cars.

  • High-performance 24V and hydraulic winches on off-road trucks.

  • Manual winches on car transporter trailers.

  • In workshops, our high-quality 220V remote-controlled lifting winches are used.


Kép


Kép
Data
Producer:
HusarWinch
EAN code:
5904024534266
Manufacturer logo:
Manufacturer logo
Warranty :
2 év
Kötél vastagság:
10.2 mm
Kötél hossz:
25.5 m
Weight:
51 kg/pcs
